Mini Crawler Excavator 1.8 T
Why Choose ZOTOOP 1.8 Ton Mini Excavator
ZOTOOP focuses on building cost-efficient, durable, and easy-to-service mini excavators for professional users. The 1.8-ton model offers an excellent balance between compact size and increased working capacity, making it one of the most versatile machines in its class.
Key advantages:
1.8 ton operating class – stronger than 1.2–1.6T models
Fully hydraulic pilot control for precision operation
EPA-certified diesel engine for U.S. compliance
Low fuel consumption and maintenance cost
Ideal for tight spaces with higher productivity
Engine Performance & Reliability
EPA-Compliant Diesel Power
Engine type: Water-cooled, four-stroke diesel engine
Fuel type: Diesel
Emission standard: EPA compliant
Cooling system: Water-cooled
ZOTOOP 1.8 Ton Mini Excavator with Kubota Engine
Fully Hydraulic Pilot Control | EPA Certified | Compact Excavator for USA Market
The ZOTOOP 1.8 ton mini excavator is a compact yet powerful construction machine engineered for U.S. contractors, equipment dealers, rental companies, and importers. Designed to meet North American job-site standards, this machine combines strong digging performance, precise hydraulic control, and long-term reliability.
With its fully hydraulic pilot control system, durable rubber tracks, and EPA-compliant diesel power, the ZOTOOP 1.8T mini excavator is an ideal solution for construction, landscaping, agriculture, utility installation, and rental applications.
Key Features
Advanced Hydraulic System.
Stable Flow, Strong Output.
High-efficiency hydraulic pump.
Optimized hydraulic pipeline layout.
Anti-wear hydraulic oil system.
The hydraulic system ensures fast response, stable pressure, and long service life, supporting continuous operation on professional job sites.
Undercarriage & Traveling System.
Stable, Durable, Job-Site Ready.
Rubber track undercarriage.
Product Parameters
Specifications | |
Operating weight | 1750kg |
Dipper Capacity | 0.04m³ |
| Dimension Length*Width*Height | 3700*1100*1850mm |
Engine power/rpm | 11.8 / 2300 (16.1 / 2300) |
Max.digging radius | 3057mm |
| Max. torque | 51.3 /1800N.m/ r/min |
| Swing speed rpm | 9.5rpm |
| Max. Grade ability | 30° |
| Bucket digging force | 16kN |
| Bucket arm digging force | 9.5kN |
Mechanical Properties | |
Max. digging radius on ground | 3840mm |
Max. digging radius | 3910mm |
Max. digging depth | 2270mm |
Max. dumping height | 2480mm |
| Maximum vertical digging depth | 1910mm |
Hydraulic System | |
Minimum turning radius | 1540mm |
Maximum Lift Of Dozer blade | 280mm |
Maximum depth Of Dozer blade | 190mm |
Hydraulic oil tank capacity | 17.5L |
Product Details
Strong traction with minimal ground damage.
Excellent stability on uneven terrain.
Suitable for indoor, residential, and urban projects.
This configuration allows the machine to operate safely on concrete, asphalt, grass, and soil.
Compact Design with Enhanced Capability.
Perfect Balance of Size and Power.
Operating weight: 1.8 tons.
Compact body for narrow access areas .
Improved digging force compared to smaller models .
The ZOTOOP 1.8T mini excavator is ideal for users who need more power than a 1.5T machine but still require compact dimensions.
Product Accessories
Strong traction with minimal ground damage
Excellent stability on uneven terrain
Suitable for indoor, residential, and urban projects
This configuration allows the machine to operate safely on concrete, asphalt, grass, and soil.
Compact Design with Enhanced Capability
Perfect Balance of Size and Power
Operating weight: 1.8 tons
Compact body for narrow access areas
Improved digging force compared to smaller models
The ZOTOOP 1.8T mini excavator is ideal for users who need more power than a 1.5T machine but still require compact dimensions.
